3kw5kw10kw high efficiency three phases output permanent magnet generators
| Minimum Order Quantity: | 1 | Price: | 4500$ |
|---|---|---|---|
| Packaging Details: | PLYWOOD CASE | Delivery Time: | 20-25 DAYS |
| Payment Terms: | T/T,L/C | Supply Ability: | 500UNITS PER MONTH |
| Place of Origin: | China | Brand Name: | BF |
| Certification: | CE | Model Number: | BF-H-5K |
|
Detail Information |
|||
| Material: | Q235&FRP | Working Tempreture: | -45-60℃ |
|---|---|---|---|
| Rotor Diameter (m): | 4 | Height Of Blades: | 3.6 |
| Rated Rotor Speed (m/s): | 150r/min | Speed Regulation Method: | Electromagnetic Control |
| Top Weight (kg): | 485kg | Start Up Wind Speed(m): | 3.2m/s |
| Sweep Wind Area(㎡): | 6.68 | Survival Wind Speed(m): | 50 |
| Rated Wind Speed(m/s): | 11 | ||
| Highlight: | 3kw permanent magnet generator,5kw high efficiency PMG,10kw three phase generator |
||
Product Description
3kW/5kW/10kW High Efficiency Three-Phase Permanent Magnet Generators
Our VAWT Wind Turbine Generator System delivers exceptional performance with high-efficiency 5kW vertical axis wind turbine operation and low startup wind speed requirements.
Generator Overview
Our Permanent Magnet Generator (PMG) is specifically engineered for vertical axis wind turbines (VAWT), offering superior performance in low to medium wind speed conditions. With a high-efficiency design and robust construction, this generator ensures reliable energy conversion, minimal maintenance, and long-term durability in both on-grid and off-grid wind power systems.
BF-H Series 5kW Generator Body
Generator Assembly
Internal Components
Generator Body Features
- High-grade Neodymium Iron Boron permanent magnets
- Each magnet tested for magnetic flux by authorized institutions
- Engineered for low starting torque requirements
- High generating efficiency through optimized internal structure
- Robust construction for long-term reliability
Wheel Hub & Connectors
Precision-engineered steel wheel hub connects blades to generator with durable blade connectors constructed from Q235 plate featuring anti-corrosion surface treatment for extended performance life.
Wheel Hub Assembly
Installation Diagram
Component Details
Construction Specifications
- Precision-made steel wheel hub
- Blade connectors made from Q235 plate
- Anti-corrosion surface treatment
- Durable performance in harsh environments
- Optimized for reliable blade connection
