Custom FRP Blade Manufacturer: Tailored to Your Wind Turbine Specifications
| Minimum Order Quantity: | 1 | Price: | $300 |
|---|---|---|---|
| Packaging Details: | plywood case | Delivery Time: | 10-15days |
| Payment Terms: | T/T | Supply Ability: | 600units/month |
| Place of Origin: | CHINA | Brand Name: | BF-H-BLADES |
| Certification: | 9001/CE | Model Number: | BF-H-BL |
|
Detail Information |
|||
| Cut-In Wind Speed: | 3 M/s | Blade Material: | Fiberglass |
|---|---|---|---|
| Rotor Diameter: | 2.3 Meters | Rated Wind Speed: | 10m/s |
| Installation: | Roof Or Ground Mounted | Voltage: | 110V/220 V DC |
| Application: | Residential, Small Commercial | Starting Torque: | Low |
| Weight: | 10kg | Type: | Vertical Axis Wind Turbine |
| Blade Number: | 5 | Power Output: | 5kW |
| Noise Level: | < 35 DB | Survival Wind Speed: | 50 M/s |
| Highlight: | custom FRP wind turbine blades,HAWT blades with warranty,tailored FRP turbine blades |
||
Product Description
Custom FRP Blade Manufacturer: Tailored to Your Wind Turbine Specifications
Our Fiber Reinforced Plastic (FRP) blades are precision-engineered for Horizontal and Vertical Axis Wind Turbines, offering an optimal balance of strength, lightweight design, and long-term weather resistance. Manufactured using advanced composite molding technology, these blades are tailored to maximize energy capture from turbulent and multi-directional wind flows, making them the ideal choice for both urban and remote installations.
Core Advantages
- Composite FRP construction ensures high structural rigidity with minimal weight, reducing rotational inertia and enabling smooth startup even at low wind speeds
- Computer-optimized airfoil profiles (e.g., NACA series) and twist distribution maximize torque output and overall annual energy yield for Darrieus or hybrid VAWT designs
- UV-resistant gel coat surface and anti-erosion coating protect against sand, moisture, salt spray, and temperature extremes (-40°C to 80°C), ensuring reliable performance in coastal or harsh environments
- Each blade is produced using closed-mold processes (RTM/VARTM) for superior dimensional accuracy, surface finish, and batch-to-batch consistency
- Custom lengths, colors, and connection interfaces are available
- Non-corrosive material eliminates rust risk; requires no painting or regular surface treatment
- Designed for a service life of 20+ years
Key Features
- High-strength glass fiber composite construction
- Optimized for vertical axis wind turbine applications
- Superior durability and weather resistance
- Lightweight design for improved efficiency
- Precision-engineered aerodynamic profile
- Corrosion-resistant materials for long service life
Technical Specifications
These advanced composite blades are manufactured using state-of-the-art processes to ensure consistent quality and performance. The glass fiber reinforcement provides the structural integrity needed for reliable operation in various wind conditions while maintaining optimal weight-to-strength ratios.
